| Main Feature |
Powerful Multimedia Features |
| Fully ATSC compliant for North America with NTIA cert. |
Photo: JPEG, BMP, PNG |
| ATSC Terrestrial broadcast channels 2-69 |
Audio: WMA, MP3, AAC (.wma, .mp3, .m4a) |
| HDMI for multimedia play, standard and high definition output |
Video: MPEG1, MPEG2, MPEG4, H264 |
| Auto and manually scan all available TV and radio channels |
Motion JPEG (.avi,.mpg,.dat,.vob,.div,.mov,.mkv,. |
| Aspect ratio 16:9 and 4:3 |
mjpeg,.ts,.trp) JPEG/Audio combo playback |
| HDMI, Coaxial, YPbPr/YUV, RCA output |
|
| Multi-language OSD & Subtitles (English/French/Spanish) |
|
| Support EPG, display Present/Next TV program |
Demodulation: |
| EIA 608 Closed Caption |
ATSC NTIA Standard, 8VSB |
| Parental control (V-Chip) |
QPSK, 64QAM, 256QAM |
| PVR ready function via USB 2.0,Timeshift function |
FEC: 1/2, 2/3, 3/4, 4/5,5/6, |
| NTSC Loop Through supported |
Guard Interval: 1/4,1/8,1/16,1/32,1/128 |
| Universal remote control |
FFT Mode: 2K, 8K, 32K |
| Tuner |
Demultiplexer |
| ATSC Terrestrial tuner |
Standard ISO/IEC 13818-1; ARIB STB-B10 |
| RF input frequency: 54-803MHz |
Input max. bit stream rate: 36Mbps (serial) / 9Mbps (parallel) |
| Bandwith: 6MHz |
|
| Input level: -83 - -5dBm |
|
| RF 3/4CH and loop through function |
|
| Decoding |
Hardware Interface |
| MPEG transport stream and A/V decoding |
Front Panel |
| Video decoder: ATSC A/72 MPEG2/4 H.264 SD&HD |
Indicators |
| Aspect ratio: 4:3, 16:9 |
IR Receiver |
| MP@HL HDTV, MP@ML SDTV |
USB: Firmware upgrade, PVR & Multimedia playback |
| ATSC formats |
LED display (Option) |
| Video resolution: 720X480 NTSC/HDMI 1080P |
|
| Audio standard: ISO/IEC 14.496-3 |
Rear Panel |
| Audio mode: mono, dual-channel, stereo |
HDMI 1.3: 576i, 576p, 720p and 1080i,1080P |
| |
Loop through output |
| |
Coaxial digital audio output: RCAx1 |
| |
L/R output: RCA x2 |
| |
CVBS |
| |
|
| Packing |
Loading |
| Unit (LxWxH) |
168*120*38mm |
Giftbox (LxWxH) |
208*180*50mm |
1x20`GP |
12000pcs |
| Packing |
32set/Carton |
Carton (LxWxH) |
434*364*420mm |
1x40`GP |
24000pcs |
| Ctn G.W. |
27 KGS |
Ctn G.W. |
29 KGS |
1x40`HQ |
29000pcs |
